Platen Boiler Reheater Superheater Alloy Steel tube 10mm-50mm
| Place of Origin | China |
|---|---|
| Brand Name | SANCO |
| Certification | ISO, ASME, EN |
| Minimum Order Quantity | 3 TONS |
| Price | Negotiated |
| Packaging Details | Customized |
| Delivery Time | 30 |
| Payment Terms | Negotiated |
| Supply Ability | 1500 ton/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Boilers, Heat Exchangers, Air Coolers, Etc. | Material | Alloy Steel , Stainless Steel，Carbon Steel |
|---|---|---|---|
| Pressure Range | Customized | Corrosion Resistance | High |
| Size | Customized | Surface Treatment | Painted |
| Tube Diameter | 10-50 Mm | Port | Zhangjiagang；Shanghai |
| Highlight | Platen boiler reheater,Alloy Steel boiler reheater,10mm platen superheater |
||
Product Description
Alloy Steel Boiler Superheater And Reheater With Good Structural Stability
Product Description
The superheater tube is using to absorb heat, and the seamless boiler steel pipe or heat-resistant alloy steel pipe is bent into a snake shape, and the two ends are welded on the inlet and outlet headers respectively. This requires the superheater tube to operate for a long time at high temperatures, so it must have good structural stability. In addition, there are good process properties, especially welding. The superheater tube is also required to have good cold workability and high oxidation resistance of the steel.
Technical Parameters
| Product Name | Steam Boiler Superheater Coils |
| Tube Material | SA192 |
| Coil Type | Serpentine Coils |
| Tube Diameter | 10-50 mm |
| Tube Thickness | Customized |
| Coil Length | Customized |
| Heat Transfer Area | Customized |
| Pressure Range | Customized |
| Temperature Range | Up to 1000°C |
| Application | Boiler |
| Warranty | 1 Year |
Advantages
Enhanced Efficiency: By superheating your steam, the MaxEfficiency Superheater allows you to extract more work from your steam turbines, increasing the overall efficiency of your power generation process.
Increased Turbine Lifespan: Superheated steam, being completely dry, reduces the risk of damage to turbine blades caused by moisture, increasing the lifespan of your turbines.
Optimal Material Selection: Built from high-quality materials capable of withstanding high temperatures and pressures, our superheater guarantees durability and long-term performance.
Ease of Maintenance: Our superheater's design allows for easy inspection and maintenance, reducing downtime and maintenance costs.
Increased Turbine Lifespan: Superheated steam, being completely dry, reduces the risk of damage to turbine blades caused by moisture, increasing the lifespan of your turbines.
Optimal Material Selection: Built from high-quality materials capable of withstanding high temperatures and pressures, our superheater guarantees durability and long-term performance.
Ease of Maintenance: Our superheater's design allows for easy inspection and maintenance, reducing downtime and maintenance costs.
Application
Our custom superheater coil is designed specifically for use in boilers and can be used to replace existing superheater coils in existing boilers, or designed and manufactured to fit into new boilers. Our superheater coil is designed to provide superior heat transfer performance and maximum durability in high-pressure and industrial applications.
| Description | Boiler superheater |
| Material | Alloy steel, Carbon steel etc. |
| Material Standard | ASTM, EN or ISO etc. |
| Structure Type | Tube Coil |
| Dimension | Customized |
| Supply Ability | 500 ton per month |
| Manufacturing Process | Material→Ingot → Hot/Cold-Rolling→ Heat treatment (Normalizing+ tempering) → Inspection →Bending tube→Assembly→Inspection →RT→Heat treatment (annealing)→Hydraulic pressure test→Painting→ Packaging |
| Thermal Efficiency | Around 95% |
Packing and Shipping
Product Packaging:
- The superheater coils will be securely packed in wooden crates to ensure safe transportation.
- The crates will be labeled with the product name, quantity, and any other necessary details.
- We take great care in packaging our products to minimize any potential damage during shipping.
Shipping:
- We offer worldwide shipping for our superheater coils.
- The shipping method and carrier will be determined based on the customer's preference and location.
- Shipping costs will be calculated and included in the final invoice.
- We strive to provide timely and efficient shipping to our customers.
FAQ
Q1: What is a Superheater Coil?
A1: Superheater Coil is a heating element used to heat the water vapor in a boiler system and increase the temperature of the steam produced by the boiler, used in various industries and provided by reliable manufacturers in China.
Q2: Where is Superheater Coil from?
A2: Superheater Coil is manufactured in China with reliable quality.
Q3: What industries use Superheater Coil?
A3: Superheater Coil is widely used in industrial applications such as food production, pharmaceuticals, petrochemicals, power plants, and other industries that require high-temperature steam.
Q4: What materials are used for Superheater Coil?
A4: Superheater Coil is made of high-grade alloy steel and stainless steel, ensuring a long service life and reliable performance.
Q5: What is the advantage of Superheater Coil?
A5: Superheater Coil is corrosion-resistant, has high heat transfer efficiency, and is easy to install and maintain.
